S-PL-1
SAFETY PLAN FOR BARRIER LENGTH OF NEED
(Click image to open PDF)
Latest Revision Note
03/01/2023 REPLACED S-PL-2 WITH S-GRS-7 AND S-GRS-7A ON GENERAL NOTE (E).
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| S-CZ-1 | CLEAR ZONE CRITERIA | FOR CLEAR ZONE DISTANCE |
| S-GRA-3 | TYPE 13 GUARDRAIL ANCHOR | SEE NOTES |
| S-PL-1A | SAFETY PLAN FOR BARRIER LENGTH OF NEED (FOR RIGID OBJECTS | SEE THE FOLLOWING |
| S-PL-1B | SAFETY PLAN FOR BARRIER LENGTH OF NEED ON CURVED ROADWAYS | SEE THE FOLLOWING |
| S-PL-3 | SAFETY PLAN: MINIMUM INSTALLATION AT BRIDGE ENDS | FOR TYPICAL BRIDGE ENDS |
| S-PL-4 | SAFETY PLAN FOR PIERS IN CLEAR ZONE | FOR BRIDGE PIERS IN CLEAR ZONE |
| S-PL-5 | SAFETY PLAN FOR BRIDGE ENDS IN MEDIANS | FOR BRIDGE ENDS IN MEDIANS |
| S-PL-6 | SAFETY PLAN: SAFETY HARDWARE PLACEMENT | FOR NARROW MEDIAN PROTECTION |
| S-PL-6A | SAFETY PLAN SAFETY HARDWARE PLACEMENT IN MEDIAN | SEE THE FOLLOWING |
| S-GRS-7 | SHORT – RADIUS GUARDRAIL SYSTEM (SRGS) | FOR SHORT- RADIUS GUARDRAIL SYSTEM AND DETAILS |
| S-GRS-7A | SHORT – RADIUS GUARDRAIL SYSTEM (SRGS) DETAILS | FOR SHORT- RADIUS GUARDRAIL SYSTEM AND DETAILS |
| S-GRT SERIES | GUARDRAIL TERMINALS | SEE THE FOLLOWING |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION |
|---|---|---|
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 07-10-2013 | 01-28-2022 | 03-01-2023 |
